Low Viscosity Silicone Potting Compound For Deep Filling Of Complex Electronic Parts
Product Overview for silicone potting compound:
HN-8806 is a two-component addition cure silicone potting compound, curable at room temperature or via heating to form high-performance elastic rubber.It features superior electrical insulation and outstanding moisture resistance, with wide working temperature range from -50°C to 250°C.Adopting low viscosity formula, it achieves thorough deep-layer curing with low shrinkage after fully cured.No heat release, no harmful by-products and no corrosion to electronic parts. Eco-friendly and fully compliant with RoHS standards.Equipped with reliable thermal conductivity, it efficiently dissipates heat generated by electronic components for stable long-term operation.
Key Features for silicone potting compound:
1. Ultra-wide working temperature range: -50°C to 250°C
2. Great low-temperature flexibility & excellent high-temperature stability
3. Strong thermal cycle resistance with low water absorption
,
Technical Parameters for silicone potting compound:
| Operating Temperature Range |
-50°C ~ +250°C |
| Water Absorption (24h) |
0.01~0.02% |
| Hardness (Shore A) |
45±5 |
| Coefficient of Thermal Expansion (CTE) |
210 μm/(m·°C) |
| Thermal Conductivity |
≥0.76 W/m·K |
Product Applications for silicone potting compound:
1. Automotive Electronics:ECU, transmission controllers & various sensors
2. Outdoor Communication Devices:5G base station units, outdoor equipment power supplies
3.Aerospace Field:Avionic parts and navigation system modules
4.Harsh Industrial Scenarios:Heat-source actuators, controllers for extreme cold & tropical environments
Usage Instructions for silicone potting compound:
1. Standard operating procedure applies.
2. For products used in extreme environments, thorough environmental reliability testing is recommended.
Important Notes for silicone potting compound:
Ensure high-quality potting; any flaws can be exacerbated under temperature cycling.
Packaging & Storage for silicone potting compound:
10kg/Set (5kg A + 5kg B)
20kg/Set (10kg A + 10kg B)
50kg/Set (25kg A + 25kg B)
Storage & Transportation
Non-toxic and non-hazardous goods. Handle as ordinary chemicals. Keep sealed and store in cool dry place at room temperature
